Technical Specifications

Product / order number
6EP1332-1SH71
Module type
PM 1207 stabilized power supply
Supported CPU / system
SIMATIC S7-1200 / S7-1200 G2 and 24 V DC loads
Supply voltage
120/230 V AC autorange input; 47-63 Hz
Integrated / available I/O
1 output, 24 V DC
Input / output signal type
Regulated, isolated DC supply
Rated output current
2.5 A
Communication interface
Not applicable
Maximum expansion / modules
Standalone supply; powers CPU and loads within the 2.5 A rating
Memory
Not applicable
Supported protocols
Not applicable
Diagnostics
Output-voltage status LED
Configuration software
Not applicable
Mounting method
35 mm DIN rail mounting
Dimensions W × H × D
70 × 100 × 75 mm

Key Features

  • Exact Siemens order number 6EP1332-1SH71; PM 1207 stabilized power supply.
  • System: SIMATIC S7-1200 / S7-1200 G2 and 24 V DC loads; supply: 120/230 V AC autorange input; 47-63 Hz.
  • I/O: 1 output, 24 V DC; signals: Regulated, isolated DC supply.
  • Output current: 2.5 A; interface: Not applicable.
  • Expansion: Standalone supply; powers CPU and loads within the 2.5 A rating; memory: Not applicable.
  • Protocols: Not applicable; diagnostics: Output-voltage status LED.
  • Configured with Not applicable; 35 mm DIN rail mounting; dimensions 70 × 100 × 75 mm.
